Power: 1.0 HP
Free Speed: 2,000 RPM
Chuck Capacity: 1/4"
Tool Weight: 2.4 lbs
Tool Length: 7.1"
Side to Center: 0.8"
Air Consumption: 30 SCFM
Sound Level: 80 dB(A)
Spindle Thread: 3/8"-24
Light weight aluminum housing
Ergonomic, handle with soft textured grip
3 planet gear system for increased life and load capacity
Teasing throttle, conveniently located reverse
Ball bearing construction throughout
Precision machined steel motor
Ring gear is machined into the motor retainer for ease of assembly and disassembly.
Planetary gear reduction assembly can be serviced without removing the chuck.
Rotor pinion is case hardened to resist wear.
Rotor, cylinder and endplates are interchangeable between different models.
This reduces the number of spare parts tool cribs need to stock.
Tipper valve and valve seat are easily accessible for service.
Committed to your success:
For nearly 90 years, Sioux Tools has been providing tools that have been designed and built by the best
engineers in the country. We use only top-quality materials in our manufacturing process, and we offer
the strongest support and warranty in the business. Our over 100 patents are an indication of our
innovation in product development and design. Sioux Tools are built tough to provide you with many
years of trouble-free service. But with any piece of equipment, service problems can occur, thus Sioux
tools are designed to make servicing quick, easy and affordable.
