Product Description
Western RM-2-4 Series Single Stage Manifold Regulator.Model: RM-2-4
Gas Service: Compressed Air
Max Capacity (SCFH) - Delivery lockup: 50
Flowing pressure: 45
Gas flow: 960
Delivery Range (PSIG): 20-160
Max Inlet Pressure (PSIG): 3000
Inlet Connection: 1-11 1/2" NPS RH M
Outlet Connection: 1-11 1/2" NPS RH F
Replacement Cartridge No.: RWC-3-49NOTE: Picture shown may not be exact unit.RM Series Manifold Regulators feature a pressure compensated single stage design (oxygen is two-stage) that delivers stable delivery pressure performance comparable to a two stage design.
The unique cartridge permits easy, single unit replacement of vital parts in minutes.
The cartridge allows the seat, nozzle, filter, spring, seals and built-in check-relief valve to be replaced without special tools and without
breaking the bonnet-to-body seal.
The cartridge can be removed and a new one installed without costly down time or removing the regulator from the pipeline.
Warranty Information
For over
40 years Western has been supplying products for the control, storage and transmission of high-pressure
gases to the industrial, medical and specialty gas markets--and leading the field in the ways that
matter most. Product designs that have changed the way gas is controlled. Product manufacturing that
sets new standards in materials, processes and functional dependability. And finished products with a
documented history of reliability which meet or exceed CGA, NFPA, and DOT requirements for safety and
performance. Whether it's fittings, regulators, transfilling equipment, gas manifold systems or oxygen
conservers, Western's products are designed and manufactured to provide unparalleled technical
accuracy for the most demanding applications. From design engineering through manufacture and into
people's lives, Western's full line of products all have one thing in common: they come from the
leader in gas control technology. Western's quality management systems are in compliance with ISO
9001-1994 and are registered by the Quality Management Institute which recognizes effective-quality
systems.
